贴片功率电感
CKD Series
Features 特点 Lowerfluxleakage,Highheatresistance 漏磁低 , 高耐热性 Applications 应用 WidelyuseinCarNavigation,Printer,Powersupplyforhouseholduse/LCDTV,LEDLightingetc. 应用于车载导航仪 , 打印机 , 家用电器 /LCD 电视
详情介绍
| Features 特点 |
| Lower flux leakage,High heat resistance |
| 漏磁低,高耐热性 |
| Applications 应用 |
| Widely use in Car Navigation,Printer,Power supply for household use/LCD TV,LED Lighting etc. |
| 应用于车载导航仪,打印机,家用电器/LCD电视电源模块,LED灯等 |
| Description 说明 |
| The maximum rated current is a DC current which causes initial inductance to decrease by 35% or temperature |
| to rise by 40°C, which is smaller (at ambient reference temperature: 20°C). |
| 额定电流，基于电感量最大下降幅35%或者温度上升至40度时,取相对较小的数据 |
|
(一般测试数据基于环境温度20°C)
|
Test Condition/测试条件: 100KHz/1V ; 1KHz/1V |
