贴片功率电感
CKRH-8D Series
Features 特点 Shieldedtype,Excellentsolderability,Highheatresistance 屏蔽结构 , 良好的可焊性 , 高耐热性 Applications 应用 WidelyuseinMonitoringequipment,Degitalcamera,CarNavigation,ECU,Caraudio, Gameinstrument,NetworkCommu
详情介绍
| Features 特点 |
| Shielded type, Excellent solderability ,High heat resistance |
| 屏蔽结构, 良好的可焊性, 高耐热性 |
| Applications 应用 |
| Widely use in Monitoring equipment,Degital camera,Car Navigation,ECU,Car audio, |
| Game instrument,Network Communication Equipment,PCetc. |
| 应用于监控设备,数码相机,车载导航仪,车载电脑,车载影音设备,游戏机,网络通信设备,笔记本电脑等 |
| Description 说明 |
| The maximum rated current is a DC current which causes initial inductance to decrease by 35% or temperature |
| to rise by 40°C, which is smaller (at ambient reference temperature: 20°C). |
| 额定电流，基于电感量最大下降幅35%或者温度上升至40度时,取相对较小的数据 |
|
(一般测试数据基于环境温度20°C)
|
|
Test Condition/测试条件: 100KHz/1V
|
