贴片功率电感
CKSLF Series
Features 特点 Shieldedtype,Excellentsolderability,Highenergystorage,Lowresistance 屏蔽结构 , 良好的可焊性 , 高能量储存 , 低电阻 Applications 应用 WidelyuseinCarLEDLighting,LEDLighting,Airconditioner,Medicalequipmentetc
详情介绍
| Features 特点 |
| Shielded type, Excellent solderability, High energy storage, Low resistance |
| 屏蔽结构, 良好的可焊性, 高能量储存, 低电阻 |
| Applications 应用 |
| Widely use in Car LED Lighting, LED Lighting, Air conditioner,Medical equipment etc. |
| 应用于汽车灯, LED照明设备, 制冷设备, 医疗设备等 |
| Description 说明 |
| The maximum rated current is a DC current which causes initial inductance to decrease by 35% or temperature |
| to rise by 40°C, which is smaller(at ambient reference temperature: 20°C). |
| 额定电流，基于电感量最大下降幅35%或者温度上升至40度时,取相对较小的数据 |
|
(一般测试数据基于环境温度20°C)
|
|
Test Condition/测试条件: 100KHz/1V ; 1KHz/1V  |
