贴片功率电感
CKRH10/12 Series
Features 特点 Shieldedtype,Excellentsolderability,Highheatresistance 屏蔽结构 , 良好的可焊性 , 高耐热性 Applications 应用 WidelyuseinMonitoringequipment,Degitalcamera,CarNavigation,ECU,Caraudio, Gameinstrument,NetworkCommu
详情介绍
| Features 特点 |
| Shielded type, larger saturation current,Excellent solderability ,High heat resistance |
| 屏蔽结构,大电流, 良好的可焊性, 高耐热性 |
| Applications 应用 |
| Widely use in Car Audio,Monitoring equipment,Printer,Power supply for household use/LCD TV, |
| Network Communication Equipment,Game instrument,PC,Medical equipment etc. |
| 应用于汽车音响设备,监控设备,打印机,家用电器/LCD TV的电源模块,网络通讯设备,游戏机,电脑,医疗设备等 |
| Description 说明 |
| The maximum rated current is a DC current which causes initial inductance to decrease by 35% or temperature |
| to rise by 40°C, which is smaller(at ambient reference temperature: 20°C). |
| 额定电流，基于电感量最大下降幅35%或者温度上升至40度时,取相对较小的数据 |
|
(一般测试数据基于环境温度20°C)
|
Test Condition/测试条件: 100KHz/1V ; 1KHz/1V  |
